This innovative module combines a high-precision gyroscope and accelerometer, along with a cutting-edge microprocessor and advanced Kalman dynamic filtering algorithm, to deliver accurate real-time attitude measurements even in dynamic environments. With a static attitude measurement accuracy of 0.1°, exceptional stability, and performance surpassing some professional inclinometers, it ensures reliable results.

The compact and cost-effective SIN-IT series features a dual-axis current output inclination sensor supporting current outputs ranging from 420mA to 525mA. Equipped with a high-precision tilt unit and low power consumption, it serves as a high-precision tilt switch with two analog current outputs for the X and Y axes. Angle ranges include ±5°, ±10°, ±15°, ±30°, ±60°, and ±90°, enabling real-time monitoring on a host computer.

With support for a serial digital interface, users can easily select the optimal connection method. The module offers adjustable serial port rates from 4800bps to 230400bps, providing flexibility and convenience.

Featuring its voltage stabilization circuit, the module operates within a working voltage range of 12V to 36V, facilitating seamless connections and ensuring reliable performance.

Capable of a maximum data output rate of 200Hz, this module allows users to selectively choose output content and adjust output rates from 0.2 to 200Hz. Stay ahead with precise and customizable data output tailored to your specific requirements.

Specifications

Accelerometer parameters

Gyroscope parameters

Pitch and roll angle parameters

Heading angle parameter

Note: [1] In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and will be subject to actual testing.

Application

· Virtual reality/augmented reality, head-mounted displays

· Large-scale agricultural automatic farming

· Safety monitoring of high-altitude operations

· Drones, manned aircraft

·Industrial attitude monitoring

·Human motion tracking/capture

· Robots, autonomous guided transport vehicles

· Pedestrian navigation

· Unmanned driving/assisted driving

·Military, intelligent weapons and equipment

Scenario application
